X-W10D4 - 10′′ (25 cm) X-Series Subwoofer (4Ω + 4Ω)
X-W10D4 - 10′′ (25 cm) X-Series Subwoofer (4Ω + 4Ω)
Alpine introduces the all-new X-Series of high-grade speakers, subwoofers and amplifiers. These products have been engineered and tuned to create a perfect match for extraordinarily dynamic, realistic sound reproduction and a spatial sound impression. With Alpine X-Series subwoofers, you get the top of Alpine’s subwoofer technology for massive and accurate bass output. These flagship subs have been engineered and tuned with highest precision and use highest grade materials.
Peak Power: 2700 Watts
RMS Power: 900 Watts
Frequency Response: 26 Hz - 200 Hz
Diaphram
- Material: Kevlar Rohacell® Layered Composite
- Design: 1-Piece Parabolic with Vented Force Transfer Assembly
Surround
- Material: Injection Molded Santoprene®
- Design: High Amplitude Multi-Roll (HAMR Surround)
Voice Coil
- Material: Aluminum Former
- Design: 2.6" (65.5mm) Voice Coil
Frame
- Material: Cast Aluminum
Terminals
- Layout: One Side
- Design: 8mm² Insert Terminals with Series/Parallel Jumper Plug
Power Handling
- Power Range: 650W-900W
- RMS Power Handling: 900W
- Peak Power Handling: 2700W
Dimensions
- Mounting Depth: 6-7/8′′ (174mm)
- Mounting Diameter: 9-1/16′′ (229mm)
- Displacement: 0.120 cu. ft. (3.4 l - Front Mount)
- Added Volume: 0.030 cu. ft. (0.8 l - Reverse Mount, Magnet Out)
General
- Frequency Response: 26Hz-200Hz
